Heat Shrink Tubing Catalog

Heat Shrink Single Wall Tubing

Part NumberMaterialDescriptionOperating Temp. Shrink RatioCertification & Military Standard
FT2TPolyolefinSingle Wall, Halogen Free, Commercial Grade. Heat Shrink Tubing-55°C to +125°C 2:1cUL
FT2PolyolefinSingle Wall, Highly Flame Retardant, General Purpose. Heat Shrink Tubing-55°C to +135°C2:1cUL, SAE-AMS-DTL-23053/5 Class 1, 2 & 3
FT3 PolyolefinSingle Wall, Highly Flexible, Flame Retardant. Heat Shrink Tubing-55°C to +135°C3:1cUL, SAE-AMS-DTL-23053/5
FT4 PolyolefinSingle Wall, High Shrink Ratio, Military Grade. Heat Shrink Tubing-55°C to +135°C4:1cUL, SAE-AMS-DTL-23053/5

Heat Shrink Medium / Heavy Wall Tubing-Adhesive Lined

Part NumberMaterialDescriptionOperating Temp. Shrink RatioCertification & Military Standard
FT2A PolyolefinDual Wall. Heat Shrink Tubing-45°C to +125°C2:1cUL, SAE-AMS-DTL-23053/4 Class 2
FT3APolyolefinDual Wall. Heat Shrink Tubing-45°C to +125°C3:1cUL, SAE-AMS-DTL-23053/4 Class 3
FT4APolyolefinDual Wall. Heat Shrink Tubing-45°C to +125°C4:1cUL, SAE-AMS-DTL-23053/4
FT3ARPolyolefinSemi-Rigid Dual Wall. Heat Shrink Tubing-45°C to +125°C3:1cUL, SAE-AMS-DTL-23053/4 Class 1
FT4ARPolyolefinSemi-Rigid Dual Wall. Heat Shrink Tubing-45°C to +125°C4:1cUL, SAE-AMS-DTL-23053/4
FT-MWH
PolyolefinMedium Wall, Water Proof. Heat Shrink Tubing-45°C to +125°C3:1SAE-AMS-DTL-23053/15, Class 1
FT-HWHPolyolefinHeavy Wall, UV Resistance. Heat Shrink Tubing -45°C to +125°C3:1SAE-AMS-DTL-23053/15, Class 2

High Temperature Resistant Heat Shrink Tubing

Part NumberMaterialDescriptionOperating Temp. Shrink RatioCertification & Military Standard
FT-PVDF175PVDFHigh Performance, Thin Wall, Kynar® Heat Shrink Tubing-55°C to +175°C2:1SAE-AMS-DTL-23053/8
FT-VIT200FluoroelastomerVery Flexible, Thin Wall, Viton® Heat Shrink Tubing-55°C to +200°C2:1SAE-AMS-DTL-23053/13
FT-PTFE260HModified PTFEHigh Temperature PTFE (Teflon®) Heat Shrink Tubing-65°C to +260°C1.7:1SAE-AMS-DTL-23053/12
FT-SIL200HSiliconeVery Flexible, Silicon Rubber Heat Shrink Tubing-50°C to +200°C1.7:1RoHs
FT-EPDMEPDMFlame Retardant, Flexible EPDM Rubber Heat Shrink Tubing -50°C to +150°C2:1RoHs

Heat Shrink Tubing for Automotive

Part NumberDescriptionOperating Temp. Shrink RatioCertification & Military Standard
FT-BPTBrake/Fuel Line Protection Heat Shrink Tubing-45°C to +105°C1.5:1RoHs
FT-AGTNon Creasing Air Groove Heat Shrink Tubing-55°C to +125°C2:1RoHs
FT-ACPHeat Shrink Tubing for Air-Conditioning Pipe-55°C to +135°C2:1RoHs
FT-HTSHeat Shrink tubing for Textile Sleeve-40°C to +125°C2:1RoHs
FT-DRTDiesel Resistant Elastomeric Heat Shrink Tubing-55°C to +150°C2:1SAE-AMS-DTL-23053/16

Heat Shrink Modulded Products and Sleeves

Part NumberDescriptionOperating Temp. Shrink RatioCertification & Military Standard
FT-CECHeat Shrink Semi-Rigid Adhesive Lined Cable End Cap-55°C to +110°C3:1, 4:1RoHs
FT-SHTSkid-proof Heat Shrink Tubing-55°C to +110°C2:1RoHs
FT-HSMTPrintable Continuous Marker Heat Shrink Tubing-55°C to +125°C2:1, 3:1RoHs
FT-IDSIdentification Sleeve Heat Shrink Tubing-55°C to +125°C2:1, 3:1RoHs
FT-SSWSSolder Sleeve Wire Splices-55°C to +125°C2:1RoHs
FT-SSSTSolder Sleeve Shield Terminators-55°C to +125°C2:1RoHs

Non-Heat Shrink Tubing

Part NumberDescriptionOperating Temp. Certification & Military Standard
FT-PTFE260 PTFE Teflon® Tube-60°C to +260°CUL
FT-SIL200Silicone Rubber Tube-60°C to +200°CUL, FDA
FT-SILB200Silicone Rubber Braided Tube-55°C to +200°CUL
FT-PVC105PVC Tube-20°C to +105°CUL
